MAGNETO LARGE ANGLE LINEAR
THE FAMILY OF MAGNETAR ANGLE LINEAR LED OPERATING AT 30W/M, 48 VDC INPUT. DELIVERING OUT STANDING PERFORMANCE OF 3000LM/M
Finish — black
MAGNETO LARGE ANGLE LINEAR — Description and Applications
Magnetic angle linear luminaires stand out with their streamlined design, providing uniform base lighting that evenly illuminates both objects and entire spaces. The body is made of extruded aluminum with a polycarbonate diffuser, offering a balance of durability and visual comfort. These luminaires are equipped with a tool-free magnetic mounting system for quick and easy installation on 48V tracks. They operate at 30 watts per meter, with color temperatures ranging from 3000K to 6000K, a chromaticity tolerance within 3 MacAdam steps, and a color rendering index above 80. Rated Class I and IP44 (or optionally Ip54).
This product can be produced in 400 and 600 mm.
Key Features
- Color Temperature: 4000 K
- CRI ≥ 80
- 50000 hour LED lifespan
- IP44 rated
| Parameter | Value |
|---|---|
| Power Consumption | 12.00 W |
| Luminous Flux | 1200 lm |
| Color Temperature | 4000 K |
| Color Rendering Index | 80 |
| Input Voltage | 48 VDC |
| LED Lifespan | 50000 hrs |
| IP Rating | IP44 |
| Mounting Type | Track |
Models & Sizes
| Model Code | Power | Dimensions | Weight | Notes |
|---|---|---|---|---|
| Magnetar Angle Linear 40 cm | 12.00W |
Verona-8-1 | 40 × 3.5 × 14 cm 140.00 × 35.00 × 400.00 |
— | Available customized lengths: 40 and 60 cm. Color temperature and body color are customized to customer requirements. |
